SS304 Stainless Steel Rope Mesh Inter Woven Knotted Type With 80x50mm Aperture For Safety Protection

Product Categories
Anping Huihao Hardware Trading Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

SS304 Stainless Steel Rope Mesh Inter Woven Knotted Type With 80x50mm Aperture For Safety Protection

Customization : Packaging & Logo, Material, Wire Rope Diameter, Mesh Size, Overall Dimension, Structure Type

Advantages : Flexible, Sturdy, Plasticity available

Brand Name : Huihao

Price : contact with us

Max width : to be your request

Sample : Free

Payment Terms : T/T,D/P,L/C,Western Union

Certification : ISO9001-2015

Application : Decoration, Protection and Isolation

Delivery Time : within 7 work days

Aperture : 80x50mm

Model Number : HH-Wire Rope Mesh

Packaging Details : wooden case, could be customized

Place of Origin : Hebei,China

rope wire dia : 1.5mm same as the first picture

Product Name : SS304 Wire Rope Mesh Net, Inter-woven (Knotted) Type, for Safety Protection

MOQ : 10 pcs filter leaf

Supply Ability : 1000 pcs per 30 days

Contact Now

SS304 Wire Rope Mesh Net Inter-woven (Knotted) Type For Fence Safety Protection
SS304 wire rope mesh, inter‑woven (knotted) type, also known as hand‑woven, knotted cable mesh, or stainless steel rope netting, is a flexible, open‑structure safety net made by interweaving stainless steel wire ropes in a plain weave pattern.
Key Features
Feature Benefit
High tensile strength The multi‑wire stranded rope construction delivers exceptional breaking strength, suitable for heavy‑duty safety and fall protection applications
Excellent corrosion resistance SS304 stainless steel offers outstanding resistance to rust, humidity, and most chemicals—ideal for outdoor and harsh environments
Superior impact and breaking resistance The knotted structure distributes impact forces across multiple rope intersections, providing excellent resistance to tearing and catastrophic failure
Exceptional flexibility No rigid ferrules or sleeve locks mean the mesh can conform to curved surfaces, irregular terrain, and dynamic load conditions
Good transparency Open diamond weave provides unobstructed viewing while maintaining a physical barrier
UV and weather resistant Performs reliably under prolonged sunlight exposure, rain, and temperature extremes
Light weight relative to strength Easy to transport, handle, and install, especially compared to welded rigid panels
100% recyclable Environmentally friendly; fully recyclable at end of service life
Cost‑effective alternative to ferrule mesh Inter‑woven construction uses no ferrules, making it more economical while offering superior flexibility for many protection applications
Specification Parameters
Parameter Specification / Range
Material grade SS304
Rope diameter 1.0mm to 6.0mm (Customizable)
Wire rope construction 7*7 or 7*19
Mesh opening 20x35mm to 70x121mm
Opening angle 60° (standard); also available 20°, 30°, 70°, 75°
Wire diameter 1.2mm, 1.6mm, 2.0mm, 2.4mm, 3.2mm, 4.0mm
Aperture 20mm-206mm
Processing Services Bending, Cutting, Uncoiling, Punching, Welding, Color Finishing
Surface finish Polishing
Application Decoration, Protection and Isolation
Certification ISO9001-2015
Applications for Safety Protection
  • Construction & Fall Protection:
    Fall arrest nets around scaffolding, elevator shafts, and bridge sites; debris containment nets on building perimeters; edge protection on open floors and roofs - catching persons and debris, distributing impact loads.
  • Infrastructure & Bridges:
    Bridge side‑protection nets along edges and beneath decks, elevated highway work zone nets, and crash‑attenuation zones in tunnels - flexible knotted structure conforms to curves and dissipates impact energy.
  • Geotechnical & Slope Protection:
    Rockfall prevention nets draped over unstable slopes, landslide debris barriers with multiple layers, and mine shaft & quarry safety barriers - flexible rope net absorbs impact and contains falling stones.
  • Industrial Safety:
    Machine guarding around moving machinery, warehouse mezzanine barriers along walkways, and crane/hoist safety zones - perimeter screening prevents operator contact while maintaining visibility.
  • Sports and Recreation:
    Golf course and sports field barrier nets behind goals, climbing wall fall‑break nets under climbing structures - safe, transparent protection for athletes and spectators.
  • Marine and Offshore:
    Oil rig and ship deck perimeter nets for fall arrest, dock and marina edge guard nets - prevents personnel overboard and equipment falls in harsh marine conditions.
Technical Principles
Weave Construction (Inter-woven/Knotted): Warp and weft wire ropes interlace in a plain over‑under pattern without ferrules. Rope‑over‑rope friction holds intersections, allowing slight sliding under load. This provides high flexibility, impact energy dissipation, and conformability to uneven terrain - ideal for perimeter fence safety.
Wire Rope Construction: 7×7 (1.2-2.4mm) uses 49 wires for stiff, abrasion‑resistant mesh suitable for general fence safety. 7×19 (3.2-4.0mm) uses 133 wires for greater flexibility and fatigue resistance, ideal for dynamic loads such as climbing or leaning on the fence.
Material Advantage: SS304 offers excellent corrosion resistance for outdoor fence safety in most environments (urban, rural, industrial). Its bright finish requires no painting, and the material is low maintenance, durable, and 100% recyclable - a cost‑effective choice for perimeter protection.
About this supplier
Company Profile: Anping County Huihao Wire Mesh Manufacture Co., Ltd. Huihao mainly produces: metal rings mesh, insulation fasteners, decoration metal mesh.
Huihao services include: pattern design, frame design, installation system design, surface finishing, mould customization.
